Technical Specification
Functions electro - mechanic – pneumatic
Ream feeding automatic - sheeter connection
or manual feed
Formats A = min. 210 max. 210 mm
B = min. 297 max. 297 mm
H = min. 20 max. 70 mm (100 mm as option)
Lateral folds ream H = min.30 - max. 60 mm (100 mm as option)
Upper folds ream H = min.20 - max.60 mm
Wrapping Paper qualityKraft and internally poly-coated paper
Wrapping Paper Substance 80 to 120 gsm
Wrapping Paper reel diameter : 750 mm
Wrapping Paper reel width 500 mm
Core size 76mm
Product to be wrap Ream paper substrate 60 to 250 gsm
Hot-melt unit Robatech-Italy
Working temperature 150°C to 180°C
Main Power supply 400/460 volts +/- 5% - 50/60 Hz–3 phases
Control circuit-PLC power-Solenoid valves 24 volts D.C.
PLC Siemens S7
Electrical plant in accordance with CE standard
(European Standards)
Colour RAL color
Wrapping paper changeover time 3 - 5 minutes
Air pressure 5/6 BAR
Air consumption 210 Nl/minute
Output based on 500 sheets ream 6-7 reams
